Auto Pocket Spring Assembling Machine
The machine to stick the pocket spring is a new model which is with high efficiency by using a more humanization design and easy operation,
. Using the inverted triangle fixed plate, to make sure each pocket spring in the right position
. The traditional time delay spring positioning has replaced by the orientation of distance, to make it more accurate.
. Achieve straight pattern and honeycomb type mattress;
. With up and down non-woven assembly function;
.Non-woven could be cut automatically after assemble one mattress;
Dimensions | 3500mm×2500mm×1750mm |
Pocket Height | 100-150mm |
Spring Diameter | 45-65mm |
Max. working width | 2200mm |
Gluing type | Interrupted,continuous ,or bit by bit |
Non-woven width | ≤2200mm |
Non-woven | ≥50g/m2 |
Max non-woven diameter | 400mm |
Working efficiency | 3row/min(45pcs/row) |
Air pressure | 6KGS/cm3 |
Power | 4.5kw |
Weight | 950kg |
